100 Piece (MOQ)
| Business Type | Supplier, Retailer |
| Application | Electroplating,Welding,Automation Machinery,Mineral Processing |
| Brand Name | Mercotac |
| Color | Black |
| Click to view more | |
Product Details
Conductors
One Conductor
Current Capacity Amps
30
Advantages
Durable,Compact,Low Cost,Signal And/or Power Connections,Easy To Install,IP 51 Protection Rating
Conductors: One Conductor
Amps: 30
The Mercotac® model 130 brushless slip ring is a compact, single-channel slip ring that is suitable for applications that require up to 30 Amps of current capacity. It is specifically designed for applications that require more current capacity than the model 110 or 110-T, but do not need the high 250-amp power of the model 1250. This slip ring is ideal for electroplating and welding uses, but can also be used in automation machinery, mineral processing and other applications
Advantages:
- Durable, compact, and low cost
- Use for signal and/or power connections
- Easy to install and replace
- IP 51 protection rating with boot kit
- Lightweight with robust metal construction
- Long-lasting, energy efficient, and no maintenance
- Made in the USA
Specification
| Model No. | Terminals | Body Material | Bearing Type | Max. Rotational Torque (gf-cm) |
Max. Voltage Rating (AC/DC) |
Max. Current Rating (Amps) |
Max. Rotational Speed (RPM) |
Operating Temp. Min °F (°C) Max °F (°C) |
Max. Frequency (MHz) | Contact Resistance (mΩ) |
Circuit Separation (MΩ) |
| 130 | 1 | Anodized Aluminum | Chrome Steel | 75 | N/A | 30 | 2000 | Min -20 (-29) Max 140 (60) |
200 | <1 | >N/A |
| 130-SS | Stainless Steel |
